Description | EX3400 48-port 10/100/1000BASE-T, 4 x 1/10GbE SFP/SFP+, 2 x 40GbE QSFP+, redundant fans, front-to-back airflow, 1 AC PSU JPSU-150-AC-AFO included (optics sold separately) |
Form factor | Fixed platform Virtual Chassis configuration consisting of up to 10 switches Junos Fusion Enterprise Satellite device |
Dimensions (W x H x D) | 17.4 x 1.7 x 13.8 in (43.7 x 4.4 x 35 cm) 1 rack unit |
Backplane speed | 160 Gbps |
Data rate | 336 Gbps |
Throughput | 250 Mpps (wire speed) |
40GBASE quad small form-factor pluggable plus transceiver (QSFP+) port densities | 2 |
100GBASE C form-factor pluggable transceiver (CFP) port densities | N/A |
Resiliency | Redundant, field-replaceable power supplies Redundant trunk groups that provide port redundancy and simplify switch configuration |
Operating system | Junos OS |
Traffic monitoring | sFlow |
Quality-of-service (QoS) queues/port | 8 unicast/4 multicast |
MAC addresses | 32,000 |
Jumbo frames | 9216 bytes |
IPv4 unicast/multicast routes | 36,000/4,000 |
IPv6 unicast/multicast routes | 18,000/2,000 |
Number of VLANs | 4,096 |
ARP entries | 16,000 |
